- 1WB HYDRAULIC HOSE一層鋼絲液壓管
|
DIN 20022(SEA100R1AT) |
||||||||||
|
HOSE REFERENCE |
Inside Diameter |
Mean Outer Cover Diameter |
Maximum Working Pressure |
Minimum Burst Pressure |
Bend Radius |
Approx Weight |
||||
|
inch |
mm |
inch |
mm |
psi |
bar |
psi |
bar |
mm |
Kg/m |
|
|
1SN-04 |
1/4 |
6.3 |
0.528 |
13.4 |
3265 |
225 |
13060 |
900 |
100 |
0.23 |
|
1SN-06 |
3/8 |
9.5 |
0.685 |
17.4 |
2610 |
180 |
10440 |
720 |
130 |
0.37 |
|
1SN-08 |
1/2 |
12.7 |
0.807 |
20.0 |
2320 |
160 |
9280 |
640 |
180 |
0.50 |
|
1SN-10 |
5/8 |
15.9 |
0.933 |
23.7 |
1890 |
130 |
7560 |
520 |
200 |
0.55 |
|
1SN-12 |
3/4 |
19.0 |
1.091 |
27.7 |
1525 |
105 |
6100 |
420 |
240 |
0.70 |
|
1SN-16 |
1 |
25.4 |
1.402 |
35.6 |
1275 |
88 |
5100 |
352 |
300 |
1.00 |
|
1SN-20 |
1 1/4 |
31.8 |
1.811 |
46.0 |
915 |
63 |
3660 |
252 |
420 |
1.20 |
|
1SN-24 |
1 1/2 |
38.0 |
2.063 |
52.4 |
725 |
50 |
2900 |
200 |
500 |
1.45 |
|
1SN-32 |
2 |
51.0 |
2.626 |
64.0 |
580 |
40 |
2320 |
160 |
630 |
1.92 |
|
1SN-40 |
2 1/2 |
63.0 |
3.039 |
77.2 |
362 |
25 |
1450 |
100 |
850 |
3.16 |
Table:Black oil resistant synthetic rubber Cover:Black oil resistant synthetic rubber
Reintorcement:One high tensite steet wire braid Temperature:-40℃ to +120℃
- 2WB HYDRAULIC HOSE二層鋼絲液壓管
|
DIN 20022(SEA100R2AT) |
||||||||||
|
HOSE REFERENCE |
Inside Diameter |
Mean Outer Cover Diameter |
Maximum Working Pressure |
Minimum Burst Pressure |
Bend Radius |
Approx Weight |
||||
|
inch |
mm |
inch |
mm |
psi |
bar |
psi |
bar |
mm |
Kg/m |
|
|
2SN-04 |
1/4 |
6.3 |
0.594 |
15.1 |
5800 |
400 |
23200 |
1600 |
100 |
0.37 |
|
2SN-06 |
3/8 |
9.5 |
0.752 |
19.1 |
4800 |
330 |
19200 |
1320 |
130 |
0.52 |
|
2SN-08 |
1/2 |
12.7 |
0.874 |
22.2 |
4000 |
276 |
16000 |
1103 |
180 |
0.62 |
|
2SN-10 |
5/8 |
15.9 |
1.000 |
25.4 |
3600 |
250 |
14400 |
1000 |
200 |
0.79 |
|
2SN-12 |
3/4 |
19.0 |
1.157 |
29.4 |
3100 |
215 |
12400 |
860 |
240 |
0.95 |
|
2SN-16 |
1 |
25.4 |
1.500 |
38.1 |
2400 |
165 |
9600 |
660 |
300 |
1.47 |
|
2SN-20 |
1 1/4 |
31.8 |
2.000 |
50.8 |
1800 |
125 |
7200 |
500 |
420 |
2.05 |
|
2SN-24 |
1 1/2 |
38.0 |
2.248 |
57.1 |
1300 |
90 |
5200 |
360 |
500 |
2.51 |
|
2SN-32 |
2 |
51.0 |
2.748 |
69.8 |
1160 |
80 |
46400 |
320 |
630 |
3.19 |
|
2SN-40 |
2 1/2 |
63.0 |
3.267 |
78.5 |
725 |
50 |
2900 |
200 |
1200 |
5.16 |
Table:Black oil resistant synthetic rubber Cover:Black oil resistant synthetic rubber
Reintorcement:Two high tensite steet wire braid Temperature:-40℃ to +120℃
- 4S HYDRAULIC HOSE四層鋼絲液壓管
|
HOSE REFERENCE |
Inside Diameter |
Mean Diameter Over Wire |
Mean Diameter Over Cover |
Working Pressure |
Minimum Barst Pressure |
Minimum Bend Radius |
Approx Weight |
||||||
|
inch |
mm |
inch |
mm |
inch |
mm |
psi |
bar |
psi |
bar |
inch |
mm |
Kg/m |
|
|
4SP-06 |
3/8 |
9.5 |
0.687 |
17.5 |
0.843 |
21.4 |
6450 |
445 |
25810 |
1780 |
7.0 |
180 |
0.75 |
|
4SP-08 |
1/2 |
12.7 |
0.795 |
20.2 |
0.969 |
24.6 |
6015 |
415 |
24070 |
1660 |
9.0 |
230 |
0.87 |
|
4SP-10 |
5/8 |
15.9 |
0.937 |
23.8 |
1.110 |
28.2 |
5.75 |
350 |
20300 |
1400 |
10.0 |
250 |
1.16 |
|
4SP-12 |
3/4 |
19.0 |
1.109 |
28.2 |
1.265 |
32.2 |
5075 |
350 |
20300 |
1400 |
12.0 |
300 |
1.50 |
|
4SP-16 |
1 |
25.4 |
1.390 |
35.3 |
1.561 |
39.7 |
4060 |
280 |
16240 |
1120 |
13.0 |
340 |
1.93 |
|
4SH-20 |
1 1/4 |
31.8 |
1.650 |
41.9 |
1.791 |
45.5 |
5071 |
350 |
20300 |
1400 |
18.0 |
460 |
2.46 |
|
4SH-24 |
1 1/2 |
38.0 |
1.922 |
48.8 |
2.106 |
53.5 |
4205 |
290 |
16820 |
1160 |
22.0 |
560 |
3.12 |
|
4SH-32 |
2 |
51.0 |
2.488 |
63.2 |
2.681 |
68.1 |
3625 |
250 |
14500 |
1000 |
28.0 |
710 |
5.21 |
Table:Black oil resistant synthetic rubber Cover:Black oil resistant synthetic rubber
Reintorcement:Four spiral wires over a layer of fabric Temperature:-40℃ to +121℃
- 4S HYDRAULIC HOSE四層鋼絲液壓管
|
Series R9R |
||||||||||
|
HOSE REFERENCE |
Inside Diameter |
Mean Outer Cover Diameter |
Maximum Working Pressure |
Minimum Burst Pressure |
Bend Radius |
Approx Weight |
||||
|
inch |
mm |
inch |
mm |
psi |
bar |
psi |
bar |
mm |
Kg/m |
|
|
R9R 06 |
3/8 |
9.5 |
0.687 |
17.5 |
6450 |
445 |
25800 |
1780 |
150 |
0.75 |
|
R9R 08 |
1/2 |
13.0 |
0.795 |
20.2 |
6000 |
415 |
24000 |
1660 |
200 |
0.87 |
|
R9R 10 |
5/8 |
16.0 |
0.943 |
23.9 |
5070 |
350 |
20300 |
1400 |
240 |
1.16 |
|
R9R 12 |
3/4 |
19.0 |
1.109 |
28.2 |
5070 |
350 |
20300 |
1400 |
280 |
1.50 |
|
R9R 16 |
1 |
25.0 |
1.390 |
35.3 |
4060 |
280 |
16250 |
1120 |
355 |
1.93 |
|
R9R 20 |
1 1/4 |
32.0 |
1.650 |
41.9 |
3045 |
210 |
12180 |
840 |
460 |
2.80 |
|
R9R 24 |
1 1/2 |
38.0 |
1.922 |
48.8 |
2675 |
185 |
10700 |
740 |
560 |
3.40 |
|
R9R 32 |
2 |
51.0 |
2.488 |
63.2 |
2375 |
165 |
9500 |
660 |
700 |
4.25 |
Table:Black oil resistant synthetic rubber Cover:Black oil resistant synthetic rubber
Reintorcement: Four spiral wires over a layer of fabric Temperature:-40℃ to +100℃
各種特殊規格歡迎洽詢！
